KAN-therm: Scope of application



Scope of application

The System is designed for internal water supply system (hot and cold tap water) and heating (cooling) installations, process heat systems and industrial systems (e.g. compressed air).

Typical working parameters of a KAN-therm Press System:

Working parameters

Pipes: PE-RT/Al/PE-HD (RT) and PE-Xc/Al/PE-Xc

Heating systems
(4 and 5 application class to ISO 10508)

Hot and cold water domestic system
(1 application class to ISO 10508)

Working temperature [°C]  80 60
T max temperature [°C]   90 80
T emergency temperature [°C] 100 100
Working pressure 10 bar 10 bar
Working parameters PE-RT and PE-Xc tubes

Heating systems
(4 and 5 application class to ISO 10508)

T working temperature [°C]  80
T max temperature [°C] 90
T emergency temperature [°C] 100
Working pressure 6 bar



















For custom use please contact our technical advisors.
