System Description:
System KAN-therm Inox is a comprehensive, modern steel installation system consisting of precision pipes and connectors made of a high quality stainless steel within a 15 – 168.3 mm range of diameters.
Purpose of the system:
The system is dedicated to internal heating, cooling, tap water, hydrant and process water systems.
The system assembly bases on a fast and simple “Press” technology – i.e. clamping connectors on a pipe. Connections are leak-tight due to a special sealing (O-ring) of a high temperature resistant rubber and a 3-point clamping system type “M“, which guarantees many years of a failure-free operation
System Advantages:
-
fast and reliable assembly of the system without using an open fire,
-
wide range of pipe and connector diameters: 15 – 168.3 mm,
-
wide range of working temperatures : -35°C - +135°C,
-
resistance to high pressure – up to 16 bar,
-
low flow resistance in pipes and fittings,
-
possible connecting with KAN-therm plastic elements/systems,
-
low weight of pipes and fittings,
-
mechanical strenght,
-
no fire hazard during assembly and operation (A - combustibility class),
-
very good look of a system,
-
function of signalisation of not ready-pressed connections.
