SYSTEM KAN-therm

Steel

∅ 12-108 mm

Complete, state-of-the-art installation system consisting of pipes and fittings made of high-grade zinc-plated carbon steel.

SYSTEM KAN-therm Steel is designed for internal, closed-circuit pressure installations - central heating, chilled water, technological heat, solar, as well as industrial (e.g. heating oil).

ITB

Easy and quick assembly

The "Press" technology used in System KAN-therm Steel makes it possible to quickly make reliable joints by pressing the connectors with generally available crimping tools, eliminating the need to thread or weld individual system elements.

The "Press" technology allows for very quick assembly, even when using large-diameter pipes and fittings.

KAN-therm - Steel system - Close-up on the basic application of the Steel system.
KAN-therm - System Steel - Safe installation with a system that signals unpressed connections.

Safety and reliability

Assembly is performed without the use of open fire, which has essential impact when replacing old heating installations in multi-family buildings.

Moreover, all system fittings are equipped with the LBP (Leak Before Press) function of signalling unpressed joints.

Advantages of System KAN-therm Steel:

  • quick and reliable system assembly
  • wide range of pipe and fitting diameters from 12 to 108mm,
  • wide range of working temperatures from -35 °C to 200 °C,
  • resistance to high pressure, to 25 bar,
  • low hydraulic resistance in pipes and fittings,
  • possibility of connecting with plastic KAN-therm systems,
  • lightweight pipes and fittings,
  • mechanical strength,
  • no fire threat during assembly and use (flammability class A),
  • high aesthetic value of installations,
  • system signalling unpressed joints LBP
KAN-therm - Steel system - Advantages of the installation.

Aesthetics and resistance to corrosion

Installations made in System KAN‑therm Steel are characterised by aesthetic look and may be used without additional paint coatings. An installation consisting of standard system elements will suit every décor.




KAN-therm - Steel system - Ideal for any room.
KAN-therm - Steel System - Capable of operating at pressures up to 25 bar and temperatures up to 200 degrees celsius.

Resistance to high pressure and temperature

Thanks to the use of the "Press" assembly technology, professional pressing tools and highest quality sealing O-rings, the system will operate at the pressure of 25 bar and the temperature of up to 200 °C.

High mechanical strength

Secures the installation, especially in generally accessible rooms, against any effects of vandalism. For this purpose, the system is particularly recommended for use in all public buildings, such as schools, shopping centres, cinemas, exhibition halls, which are particularly exposed to such actions.

KAN-therm - Steel system - High strength of materials.
